Meetyou Machinery China Profile Production Line Manufacturing Custom PVC PE Pipe Profiles Traction Machine Wholesale High-Quality PVC Profile Extrusion Machine

Product Description

Zhangjiagang Meetyou Machinery Co., Ltd.

Factory Add: Leyu Economical Park, Suzhou, Jiangsu, China
Zhangjiagang MEETYOU Machinery Co., Ltd is located in the national civilized city---Zhangjiagang, which belongs to Suzhou city of Jiangsu Province; It′ S near the golden waterway of the Yangtze River, only 2-3 hours from Shanghai deep-water port and Pudong airport, and 1 hour from Wuxi city and Changzhou city by car.
MEETYOU Machinery is a leading supplier of plastic extrusion and recycling equipment.
We mainly offer kinds of PVC/PP/PE/ABS/PC extrusion lines for pipes, profiles, granules, sheets/boards, roof tiles, and recycling machines for pipes, profiles, film, woven bags, bottles, tires, net, etc.
Besides, we also offer the assistant machines, like Mixer, Crusher, Pulverizer, pipe Belling Machine, Auto Loader, Hopper Dryer, Water Chiller, words Printer, etc.
Product Description
Application: YF series profile extrusion line equipped with conical twin screw extruder or parallel is used for PVC plastic window profiles, steel plastic composite profiles, decorative profiles, etc. Properties and advantages: This line features stable plasticity, high output, low sheering force, long life service, and other advantages. The production line consists of the control system, conical twin-screw extruder, calibration unit, haul-off unit, cutter, film covering machine, and stacked, the extruder is equipped with an advanced AC inverter, imported temperature controller(RKC, Japan). the calibration unit's vacuum pump and haul-off unit's motors are famous brand products. after a simple changing of the die and screw, it also can produce the foam profiles.

Product Parameters
MEETYOU MACHINERY China Profile Production Line Manufacturing Custom PVC PE Pipe Profiles Traction Machine Wholesale High-quality PVC Profile Extrusion Machine

Main technical data
Mode	Products max width (mm)	Max capacity (kg/h)	Extruder mode	Extruder power (kw)	Cooling water (m³/h)
WPC-300	300	240	SJZ65/132	37	7/7
WPC-500	500	350	SJZ80/156	55	8
WPC-900	900	350	SJZ80/156	55	9
WPC-1200	1200	450	SJZ92/188	110	10

High speed main technical parameter
type	YF240	YF240	YF240A
Max.width of product(mm)	240	240	150*2
Extruder model	SJP75/28	SJP93/30	SJP110/28
Max extrusion capacity(kg/h)	150-250	250-400	400-500
Extruder motor power(kw)	45	55	90
Cooling water(m³/h)	7	8	10
compressed air(m³/min)	0.6	0.6	0.8

Classic type main technical parameter
Type	YF108	YF240	YF240A	YF300	YF400
Max width of product(mm)	108	240	150*2	300	400
Extruder model	SJZ55/110	SJZ65/132	SJZ65/132	SJZ65/132	SJZ80/156
Max extrusion capacity(kg/h)	110	180	180	180	320
Extruder power(kW)	22	37	37	37	55
Cooling water(m³/h)	7	8	8	8	10
Compressed air(m³/min)	0.6	0.6	0.8	0.6	0.6

Detailed Photos
FAQ
YOU ARE WELCOME TO OUR FACTORY AT ANY TIME
- MEETYOU MECHINERY is original manufacturer.
- If you interested in our products and we can fulfill your request , you may pay a visit to MEETYOU MACHINERY Factory.
- The meaning of visiting supplier, since seeing is believing, MEETYOU MACHINERY with its own manufacture and developed& research team, we can send you engineers and make sure the high-efficiency after-sales service.
SEE MEETYOU MACHINE HOW TO ENSURE THE QUALITY
- In order to ensure the accuracy of each part, we are equipped with a variety of professional processing equipment and we have accumulated professional processing methods over the past years.
- Each component before assembly needs strict control by inspecting personnel.
- Each assembly is in charge of a master who has working experience for more than 15 years
- After all the equipment is completed, we will connect all the machines and run the full production line for at least 12 hours to ensure the stable running in the customers' factory
THE AFTER-SALE SERVICE OF MEETYOU MACHINERY
- After finishing the production, we will debug the production line, take photos, and videos and send them to customers via mail or instant tools.
- After the commissioning, we will package the equipment by the standard export package for shipment.
- According to the customer's request, we can arrange our engineers to customers' factories to do the installation and training.
- Engineers, sales managers, and after-sales service managers will form an after-sales team, online and offline, to follow the customers' project.
