China Factory Sale 24W Wall Mount Type Lithium Battery Chargers
| US$2.00-8.00 | 1,000 Pieces (MOQ) |
Basic Info.
Model NO.
YS18
Certification
TUV, RoHS, ISO9001, CCC
Color
Black
Type
OEM
Internal Structure
On-Off Type
Power Source
Half-Bridge Type
Connection
Plug In
Bluetooth Standard
2.2
Brand
Yingjiao/OEM/ODM
Experience
20 Years′experience
Quick Delievery
15-25 Days
Warranty
3 Years′ Warranty
Packaging
PE Bag,White Box,Carton
Transport Package
PE Bag, White Box, Carton
Specification
TUV/GS/CE
Trademark
Yingjiao&OEM
Origin
Ningbo, China
HS Code
8504401400
Production Capacity
2, 000 PCS/Day
Product Description
China Factory Sale 24W Wall Mount Type Lithium Battery ChargersFeatures:
Universal Input: 100-240V AC 50/60Hz
Safety: TUV/GS/CE compliance
RoHS Compliance
High efficiency & low power consumption
Short Circuit Protection
Over Current Protection
Over Voltage Protection
Light Weight & Compact
Environmental:
Operating Temperature: 0 ~ +40 degrees centigrade
Storage Temperature: -40 ~+70 degrees centigrade
Operating Humidity: 10% ~ 90% RH Non-condensing
Storage Humidity: 5% ~ 95% RH Non-condensing
Mechanical:
Dimensions: 76mm (L)*43mm (W)*31mm (H)
N. W.: 65g
AC Input Plug: European 2 round pin
Output plug: Optional
DATA:
| Switching power adapter | |
| Model: | YS18A |
| Power: | 24W max. |
| Input: | 100-240VAC 50/60Hz |
| Output Voltage: | 5-36V |
| Output Current: | 0.1-3A |
| Input current: | 0.5A max. |
| Inrush Current: | 65 Amps max. at 230VAC/50Hz,full load |
| Leakage Current: | 25mA Max. at 264VAC input |
| Energy Efficiency Level VI : | CoC 5 / DoE 6 / CEC VI |
| No Load Power Consumption : | <0.075W |
| Protections: | Short Circuit /Over Current /Over Voltage |
| Short Circuit Protection (SCP): | Protection to Zero Voltage |
| Over Voltage Protection (OVP): | ≤Vout*150% |
| Over Current Protection (OCP): | 110%-180% |
| Working TEMP.: | -20°C-50°C |
| Working Humidity: | 5%-90% RH non-condensing |
| Storage TEMP.,Humidity and altitude: | -40ºC ~+70°C ambient temperature and a 5% to 95% relative humidity range throughout an altitude range of -60 meters to +5000 meters AMSL. |
| Input Plug: | AU 2pin |
| Certificates and approvals: | UL,GS,CE,EMC,SAA,FCC,CB,PSE,CCC,RoHS,REACH |
| EMI EMISSION: | Radiation Test&Conduction Test: EN 55022/FCC Part 15 Harmonic Test : EN 61000-3-2 Flicker Test : EN 61000-3-3 |
| EMS IMMUNITY: | ESDTest:EN 61000-4-2 RSTest:EN 61000-4-3 EFTTest:EN 61000-4-4 Surge Test:EN 61000-4-5 CSTest:EN 61000-4-6 MFTest:EN 61000-4-8 DIPTest:EN 61000-4-11 |
| MTBF: | 100000 hours minimum at full load at 25ºC ambient |
| Life: | 3-5 years alternative |
| Dimension: | 76*43*32mm |
| Weight: | 120g |
| Packing: | 100PCS/CTN,52.5*31*31mm |
Details:
| Model: | YS18-0503000 | YS18-0902500 | YS18-1202000 | YS18-1801200 | YS18-2401000 | YS18-3600600 |
| DC Voltage: | 5V | 9V | 12V | 18V | 24V | 36V |
| Rated Current: | 3A | 2.5A | 2A | 1.2A | 1A | 0.6A |
| Current Range: | 0-3A | 0-2.5A | 0-2A | 0-1.0A | 0-1A | 0-0.6A |
| Rated Power: | 15W | 22.5W | 24W | 21.6W | 24W | 21.6W |
| Ripple & Noise(max.): | 50mVp-p | 90mVp-p | 120mVp-p | 180mVp-p | 240mVp-p | 300mVp-p |
| Voltage Tolerance: | ±5% | ±5% | ±5% | ±5% | ±5% | ±5% |
| Line Regulation: | ±3% | ±3% | ±3% | ±3% | ±3% | ±3% |
| Load Regulation: | ±5% | ±5% | ±5% | ±5% | ±5% | ±5% |
| Efficiency: | 81.84% | 86.52% | 86.80% | 86.33% | 86.80% | 86.33% |
| Setup,Rise,Hold up time: | 3 second max./40 MS max./5 MS max. at 100VAC input and output max. load. | |||||
