Paper Machine Roller Vacuum Suction Press Roll/Wire Drive Roll/Wire Guide Roll

Product Description

Product Description
Paper Machine Vacuum Suction Press Roll
Application: Paper machine press section
Form: Single-chamber pre-press, single-chamber main pressure, double-chamber or three-chamber, suction press, three-roll two-pressure, four-roll two-pressure, four-roll three-pressure
Component:
Adhesive surface: rubber thickness 20-25mm, rubber hardness "A" 95±2°, rubber surface is drilled φ3.5mm~φ4mm, opening rate is about 15~20%.
Roller body: stainless steel 304 coil, wall thickness 40~70mm, roller surface drilled φ4~φ5mm.
Vacuum box: cast iron or stainless steel 304 plate welding. Built-in water spray pipe, air cushion pipe and adjusting rod.
Operation side bearing seat, transmission side bearing seat.
Detailed Photos

Product Parameters
The bottom roll of the vacuum return roll should be equipped with a white water pan with a large wrap angle to cover the roll except the part wrapped by the fabric, so that the white water in the roll hole can be thrown into the white water pan.

Product Name	Vacuum roll
Application	Paper machine
Roller Material	Carbon/stainless steel,Aluminum alloy or other specified material
Diameter	460-1600mm
Length	2100-12000mm
Color	Customers' Request
Surface treatment	Trivalent chromium galvanized, chrome, paint, anodized, Teflon spray
Certificate	ISO9001
Type	Make-to-order

The adhesive layer have good elasticity, compression resistance, flex resistance and thermal conductivity.
The maximum tolerance of the hardness should be within the allowable range, otherwise the unevenness of the pulp will be uneven and the quality of the paper will be affected.
Generally, the Shore hardness is 40°~100°, and the tolerance is ±2°~±4°. Stainless steel rolls body have the following advantages over tin bronze rolls: 1.Has higher rigidity and mechanical strength. Its tensile yield strength and impact toughness are more than double that of copper, which is conducive to improving the dehydration rate.
2.Has higher hardness and abrasion resistance, good impact toughness. It does not deform during long-term high alternating load operation, which is incomparable with copper structure.
3.It has high hardness and abrasion resistance, has extremely high corrosion fatigue strength and ability to resist corrosion cracking and corrosion wear, which is 2-3 times that of copper alloys, and the service life is also increased by more than 2-3 times.
