Basic Info.
Model NO.
KLT-OIS-3A-AF-IMX258 V1.0
Specification
1.12 um x 1.12 um
Production Capacity
500000 Pieces
Product Description
13MP IMX258 OIS MGS MIPI-Schnittstelle Autofokus Kameramodul
Kameramodul Nr. KLT-OIS-3A-AF-IMX258 V1.0
| Kameramodul Nr. | KLT-OIS-3A-AF-IMX258 V1.0 |
| Auflösung | 13MP |
| Bildsensor | IMX258 mit MGS OIS |
| Sensorart | 1/3.06" |
| Pixel Größe | 1.12 um x 1.12 um |
| EFL | 2.35 mm |
| F.NO | 2.40 |
| Stabilisierungsmethode | Optische Bildstabilisierung (OIS) |
| Stabilisatortyp | Mikro-Gimbal-Stabilisator (MGS) |
| Stabilisator Achse Nr. | 2 Achsen (Pitch und Yaw) |
| Stabilisatorwinkel | Max. 3.0° |
| Stabilisatorleistung | 180 mW |
| Pixel | 4224 x 3136 |
| Betrachtungswinkel | 127.0°(DFOV) 95.5°(HFOV) 70.0°(VFOV) |
| Linsenabmessungen | 19.0 x 19.0 x 9.90 mm |
| Modultyp | Autofokus |
| Autofokus-VCM-Treiber-IC | DW9763 |
| Linsenmodell | KLT-LENS-TK1267 |
| Schnittstelle | MIPI |
| Linsentyp | 650 nm IR-Schnitt |
| Betriebstemperatur | -20°C to +70°C |
| Gegenstecker | BAF04-30083-0500 |
