Demark Energy Saving Pet Plastic Bottle Automatic Rotary Stretch Blow Molding Machine

Product Description

Our Advantages
High Output, High Technology for multi serve applications
○ DMK-R is the series of rotary blow molding machines, adopting the bi-directionastretching principle. This new design is widely used for blow up high-quality PET bottles at fast speed.
○ DMK-R blow molding machine is capable to meet any packaging challenge. It canbe either utilized in stand-alone production line or integrated with filling machine. DMK-R blow molding machines are functional, accessible, user-friendly, aimed inmaximum uptime.
○ Cut 30%% biowing costs.
○ Reduce 46% power consumption.
Product Description
working process
1 Preform Feeding :Preforms are fed by star-wheel to load onto chain spindles continuously.
2 Preform Heating :During heating, the preforms are constantly rotated for a perfectlysymmetrical distribution of heat. The necks of the preform are protectedfrom oven-heating by means of protection ramp with cold water.
3\4 Pitch Changeover :After heating,the preforms go into pitch-change by servo motorBy slider, the abutting preform's center distance changes from50.8mm to mold's center distance.
5 Stretching & Blowing :After pitch changeover, the preforms are sent into the mold, The longitudinalstretching of the preform is carried out by a servo motor, then is pre-blow,nigh-pressure blow and exhaust.
6 Bottle Discharging :The blown bottles are removed from the molds by servo motor, and be evacuatedeither in bulk or directly feed to the filling lines via sucking conveyor.
Product Parameters

Suitable for:	non-carbonated and carbonated water, soft drinks,juice,tea,isotonic beverages, milk and dairy products, beer, oil and sauces and HPC products
Output:	10000 to 30,000 bottles/h
Output:	10000 to 30,000 bottles/h
