Full-Feed Rice Combine Harvester, Corn Combine Harvester Agriculture Machinery

Product Description

Product Description

Company Profile
Product Parameters

Technical Specification of 4LL-2.0A Combine Harvester
/ Item		Unit	Description
Complete Machine	Model	/	4LL-2.0D
	(xx) Overall Dimension( L x W x H)	mm	4680 × 2500 × 2605
	Cutting Width	mm	2000
	Complete Machine Weight	kg	3150
	Feeding Capacity	kg/s	4
	Min. Ground Clearance	mm	265
	Rubber Track	mm	450*90*49
	Threshing Cylinder	mm	Φ540 x 1285 Φ540 x 650
	Grain Tank Capacity	L	550
	Oil Tank Capacity	L	120
	Working Efficiency	hm2/h	0.3-0.5
	Oil Consumption	kg/hm2	≤30
	HST	/	45cc
Engine	Model	/	Xinchai stage
	Type	/	,,, Four Cylinders, Intercooling, Turbo, 4 Strokes
	Standard Power	kw	65
	Standard Speed	r/min	2400
Gearbox	Model	/
	Gears	/	Three gears

Our Advantages
Ease of Operation: Equipped with hydraulic stepless speed change and hydraulic steering, along with a semi-feed-in specific transmission box, making operation convenient and effortless. High cutting platform lifting height for easier downhill and over-ridge maneuvering.
Excellent Operational Performance: Features a domestically pioneered large-diameter double threshing roller, adjustable sieve reciprocating vibration screen, and a crushing-before-conveying secondary lifting and re-threshing auger, ensuring high efficiency, energy conservation, and strong adaptability. Ultra-wide low-speed middle conveyor trough with low noise and no blockage. 1080mm ultra-wide cleaning chamber and adjustable fan speed for minimal loss and high cleanliness.
Flexible Configurations: Optional low-loss rape harvesting auxiliary platform for harvesting rape. Optional large grain bin hydraulic unloading for ease and convenience. Optional built-in straw crushing and spreading device for safe, reliable, and uniform operation.
Packaging & Shipping
Q&A
Q1: Are you a factory or trading company? We have our factory for the farm machines and we also have our own trading company with self-supported import and export right. Q2: How can I trust on your company? We are a fully registered manufacture and exporting company by China Export Registration Authorities. Moreover, our products have been exporting to a number of countries including Switzerland, Russia, Spain, Netherlands, Australia, Peru, Thailand, Pakistan, Indonesia, Tanzania, Nigeria, South Africa, Sudan, Congo etc. Q3: Where is your factory located? How can I visit there? Our factory is located in Linyi City, Shandong Province, China. About 1 hour away from Linyi Airport, 4 hours away from Qingdao airport. All our clients are warmly welcomed to visit us! Q4: How can I place an order from your website? It is very easy.Once you find the implement you need on our website and place an inquiry against it, or, get to the inquiry section and leave us a message there with name, country and phone number, we will get in touch with you at the earliest. Q5: How can I make the payment? Payment is made via Telegraphic Transfer (T/T) through the bank against the proforma invoice. 30% as prepayment and the balance when the goods are ready for shipping. Q6: What's the Payment terms? T/T, L/C or some other ways payment method.Q7: At which port do you usually ship the good? We usually ship goods via Qingdao port of China. Q8: How about the Warranty ? 12 months warranty from the time of the goods arrive at destination.
QC Flow
1. Material inspection before production to avoid any potential problem from the very beginning.
2. Inspection for half-finished products during order production to find the problem earlier if any;
3. Inspection for finished products after production to make sure the products comply with customer's requirement.Department Introduction of QC / Technical Support:In order to get super quality, we have special QC department to control the product quality. This department is composed by experienced engineers who can offer us strong technical support easily. The engineers will inspect product quality both in order production and after order production to make sure each shipment we send to our customers is in the best status. With their strict quality control, our consistent quality wins us more and more orders from our international customers.Full Service and Product Warranty:We offer our customers technical assistance and a full one year warranty on all products covering all manufacturing defects. Our manufacturing facility is completely computerized to provide our customers efficiency, reliability, high quality and timely shipments.Spare Parts:We can supply spare parts within 15 business days or sooner. Currently, part numbers are not available on-line. You may however determine the part number from your Parts Book or, if it is a simple part, you may describe the part and send us an order online. If you are not sure, please Contact Us .Shipment: We can ship from our port in Qingdao or Shanghai, China to anywhere in the world within short days
After Sales Service
PRE-SALE SERVICEWe have 8-24 hours online staff to answer your technology questions and know your requirements. our staff can provide you the professional designs and recommend you the most suitable machine types.
SALES SERVICE Provideusers with comprehensive technical support,with the user selection,to provide the most economical and reasonable program. In accordance with the contract delivery time for your timely delivery,if have special requirement,our company can organize pro duction,and strive to meet user needs.
AFTER-SALES SERVICEWe have 24 hours online staff to answer your technology questions and know your requirement. Our staff can provide you the professional design andrecommend you the most suitable machine type.SALES GOALWe hope our outstanding quality goods and good service could make you to set up the best competitive advantages in your market.
