Digital Measuring Microscope (STM-2515M)
| Negotiable | 1 Piece (MOQ) |
Basic Info.
Model NO.
STM-2515M
Number of Cylinder
Binoculars
Mobility
Desktop
Shape
Cylindrical Shaped Lens
Principle
Optics
X,Y,Z-Axis Accuracy
±(3+L/200)Um
Metal Stage Size
408 X 280mm
Glass Stage Size
306 X 196mm
X,Y-Axis Travel
200 X196mm
Z-Axis Travel
150mm
Dimension(Dxwxh)
530X540X850mm
Net Weight
110kg
Contour
Adjustable 256-Frade LED Illumination
Surface
Adjustable 256-Frade LED Illumination
Coaxial
Adjustable LED Coaxial Illumination
Transport Package
Plywood
Specification
CE
Trademark
SINOWON
Origin
Dongguan
HS Code
90318020
Production Capacity
200
Product Description
Product Features:* Bright field observation, clear and flare less obverse image, wide field of view.
* Long working distance objectives, up to optical 1000x magnification.
* Aperture diaphragms in the transmitted illumination and reflected illumination system as
standard feature.
*The quick-release system, which is especially useful in long-stroke measurements
* Focus and measure using the fine/coarse movement handle with the large-size grips on both
sides of the column.
* Zero-set switches (X- and Y-axis) are also located near the stage feed handles.
* Available with the Vision Unit for upgrading to a vision measuring system.
Specification:
| Microscope Model | STM-2515M | |
| Code # | 532-180 | |
| X/Y-axis travel | 250x150mm | |
| Scale Resolution | 0.0001mm | |
| XY Stage Measuring Accuracy at 20ºC. | (2+L/200) μm L: measuring length | |
| Observation Image | Obverse image (Erect Image is available) | |
| Eyepiece Tube | Binocular Eyepiece: WF10/20 | |
| Objective Lens | Standard delivery: 5x ,10X, 20X, 50x; Optional: 100x | |
| Contour Illumination | Adjustable LED | |
| Surface Illumination | Adjustable LED | |
| Z Axis Travel Range | Standard focus travel:150mm, 200mm is optional | |
| Z Axis Focusing | Manual focusing (Coarse/fine) | |
| XY Stage Floating Function | Quick release mechanism | |
| Display Unit Function | Zero setting, Direction switching, Data output via RS-232 | |
| Power Supply | AC220/50HZ; AC110V/60Hz | |
| Optional Accessories | High-Precision Rotary Table RT4(D:165mm), RT5(262mm) | |
| Digital Readout DP300 | ||
| Quickmeasuring Measuring Software QM2.0 | ||
| CCD adapter and CCD camera | ||
Optical Specification:
| Name | Objective | Eyepiece WF10/22 | |||||
| N.A. | W.D.(mm) | f(mm) | R(um) | ±p(um) | Magnification | Visual Field(mm) | |
| 5x | 0.15 | 11.6 | 40 | 2.1 | 16.3 | 50x | ¢4.4 |
| 10x | 0.3 | 6.3 | 20 | 0.9 | 3.1 | 100x | ¢2.2 |
| 20x | 0.4 | 10.3 | 10 | 0.69 | 1.8 | 200x | ¢1.1 |
| 50x | 0.8 | 2 | 4 | 0.34 | 0.4 | 500x | ¢0.44 |
| 100x | 0.8 | 1.96 | 2 | 0.34 | 0.2 | 100x | ¢0.22 |
