Imported Chemical Fiber Top Press Felt for Paper Making Machine

Product Description

Product Description
The press felt plays an important role in removing the water from the paper web after the forming section, and at the same time imparting smoothness and conveying it to the dryer section. For this reason, the press felt needs to provide the following functions: water removal, smoothness and runnability.
According to the location on the paper machine can be divided into wet felts, top felt and dryer felt. The function of the wet felt is to press the raw paper to make it dehydrated and smooth the paper surface. The top felt is used above the wet felt and plays the role of leading, flattening paper and drying. Dryer felt wraps the dryer cylinder to iron and dry the pape.
Structure of Felt
Advantages of Press Felt /Paper making Felt:
1. High anti-compaction capacity.
2. Extremely high elasticity and recoverability.
3. Strong drainability and larger void volumn.
4. Smooth felt surface and even pressure distribution.
5.Long holding time of wear resistance and plastic strength of felt
Design of Felt
Design of press felt /paper making felt /MG felt
According to paper machine and paper, we can change the structure of base mesh.
It has the characters of anti-high pressure, good elasticity and filterability, stable size, small elongation, great strength, affective to eliminate grooving, vacuum mark, blind-hole mark and other marks.
Suitable to vacuum press, kinds of complex press and other press for producing high grad offset paper, and kinds of high grade paper and paper board etc.
Technical Parameters

The type of paper making felt
Felt series		Application		Technical Parameter
Single Layer BOM Felt	Single Layer Forming BOM Felt	Paper machine	Cylinder, Super Forming, Fourdrinier, Inclined Wire Machine, Nip Wire Machine etc.	Felt GSM	700-1200g/m2
	Single Layer Press BOM Felt	Working speed	≤800m/min	Felt GSM Tolerance	≤±4%
				Air Permeability	30-120cfm
	Single Layer Top BOM Felt	Paper kind	≥8g/m2 all kinds of paper	Tensile Strength	≥2000N/5cm
				Elongation Percentage	≤1%
	1.5 Layer BOM Pulp(Paper) Felt	Line pressure	≤80KN/m	Width Variation	≤±2cm
Double Layer BOM Felt	Double Layer Forming BOM Felt	Paper machine	Multi-Cylinder, Super Forming, Fourdrinier, Superposition Wire, Nip Wire Paper Making Machine etc for different kinds of paper machine	Felt GSM	950-1450g/m2
				Felt GSM Tolerance	≤±4%
	Double Layer Press BOM Felt	Working speed	≤1000m/min	Air Permeability	30-110cfm
	Double Layer BOM Special Composite Press Felt	Paper kind	≥8g/m2 all kinds of paper	Tensile Strength	≥3000N/5cm
				Elongation Percentage	≤0.6%
	Double Layer Top BOM Felt	Line pressure	60-200KN/m	Width Variation	≤±2cm
Triple Layer BOM Felt	Tri-layer BOM For Large Roll Felt	Paper machine	Medium/high working speed paper machine of Multi-cylinder, Fourdrinier, Superposition Wire, Vacuum Composite Press, Large Diameter Roll Press, Shoe Press etc.	Felt GSM	145-1800g/m2
				Felt GSM Tolerance	≤±4%
				Air Permeability	40-90cfm
	Tri-layer BOM For Shoe Press	Working speed	≤1000m/min	Tensile Strength	≥4500N/5cm
		Paper kind	≥40g/m2 newsprint, write paper,high-grade board paper etc.	Elongation Percentage	≤0.6%
	Tri-layer BOM Hot Press	Line pressure	≥200KN/m	Width Variation	≤±2cm

Detailed Photos
Packaging & Shipping
Company Profile
We are a China industrial felt and fabric manufacturer located at Jiangsu province,Xuzhou city. With advantage technology and excellent produce equipment,we provide one-stop service from consultation,process design and optimization , manufacture ,installation , commissioning and personnel training and so on.At the meantime,we can custom design according to customers' requirements. Now, in addition to providing high-quality products and basic services, we pay more attention to providing customers with technical support and a complete set of solutions. Through our professional analysis, we can reduce customers' costs, enhance their competitiveness, and provide customers with one-stop industrial fabric solutions.
Leizhan corporate spirit : "Unity, innovation, pragmatism, and truth-seeking".
Since the establishment of Leizhan, we have insisted on taking customer needs as our core, thinking about what customers think, worrying about what customers need, and striving to achieve customer satisfaction. We insist on growing and succeeding together with customers, and have established long-term stable and successful cooperative relations with customers in 35 countries.
We are united. In today's globalization, we unite with our customers, develop together, and make customers more successful.
Thank you for browsing, we are offering free sample now,
if you have any needs, please feel free to contact us at any time, wish you a happy day
