Module spare parts PROSOFT AN-X2-AB-DHRIO

Product Details

Product Description

Product Description
Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands

PROSOFT AN-X2-AB-DHRIO

. Unpack and check the delivery. If damage is found, notify the supplier. 2. Place the panel cut out where the operator panel is to be situated, draw along the outer sides of the holes and cut according to the markings. If access to the text strip is needed, add extra space in the lower left corner. Place the operator panel on a stable surface during installation. Dropping it or letting it fall may cause damage. x 6 Panel cut out 245.5 x 138.5 mm (9.67 x 5.45 inch) 5.0 mm 18.0 mm For text strip (0.20 inch) (0.71 inch) Section 3 Installation Installation Process 3BSE043449R501 15 3. Secure the operator panel in position, using all the fastening holes and the provided brackets and screws: 4. Connect the cables in the specified order. Ensure that the operator panel and the controller system have the same electrical grounding (reference voltage level), otherwise errors in communication may occur. Use an M5 screw and a grounding conductor (as short as possible) with a cross-section of minimum 2.5 mm2. - Use only shielded communication cables. - Separate high voltage cables from signal and supply cables. - The operator panel must be brought to ambient temperature before it is started up. If condensation forms, ensure that the operator panel is dry before connecting it to the power outlet. - Ensure that the voltage and polarity of the power source is correct
