ODM OEM Patented Magnetic Coupling Stirring Agitator Zero Leakage Pressure Tank
| US$46,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
FCHA
Function
Storage Pressure Vessel, Separation Pressure Vessel, Heat Pressure Vessel, Reaction Pressure Vessel
Application
Customized
Material
Customized
Pressure
Customized
Storage Medium
Customized
Pressure Level
Customized
Condition
New
Lead Time
2 to 3 Months
OEM
Available
ODM
Available
Work Life
10 Years
Branch Office
California, USA
Specification
5000L
Trademark
LUHAO
Origin
China
HS Code
84198990
Product Description
With the demand for environmental protection in the new era, hydrogenation is the most environmentally friendly chemical process, gradually replacing the process of severe pollution that is not conducive to environmental protection. It is applied in the three-phase catalytic hydrogenation of gas, liquid, and solid, which is a reaction process between hydrogen and other compounds. It is divided into single-sided hydrogenation and double-sided hydrogenation. The process of high-pressure hydrogen gas consumption to low-pressure is accompanied by hydrogenation heat, also known as exothermic reaction. Hydrogen is a flammable and explosive substance, and there must be safety measures for the hydrogenation process.Magnetic coupling drive with static sealing, zero leakage, long service life, simple installation, safe and environmentally friendly.
| MODEL | FCHA200-600L | FCHA800-2000L | FCHA2500-5000L | FCHA6000-10000L | FCHA12000-20000L |
| CAPACITY | 200-600L | 800-2000L | 2500-5000L | 6000-10000L | 12000-20000L |
| WORK PRESSURE MPa | -0.1-10.0 | -0.1-10.0 | -0.1-10.0 | -0.1-10.0 | -0.1-8.0 |
| WORK TEMPERATURE C° | -15-320 | -15-320 | -15-320 | -15-320 | -15-320 |
| rpm | 0-320 | 0-320 | 0-320 | 0-320 | 0-320 |
| Motor power KW | 3.0-11.0 | 11.0-22.0 | 15-37.0 | 22.0-55.0 | 37.0-75.0 |
| Main materials | 09MnNiDR/16MnDR (low-temperature steel), 15CrMoR (high-temperature steel), stainless steel S30408/S32168/S31603, S39042, titanium material, duplex steel, shackle material, Hastelloy alloy, zirconium material, Monel, and other materials used for explosive composite plates. | ||||
| Heating form | Jacketed thermal oil, jacketed steam, outer half pipe, inner coil pipe. | ||||
| Mixing form | Turbine self suction, disc turbine, asymmetric turbine, four wide blade, axial flow combination self suction. | ||||
| Shaft sealing form | Magnetic coupling drive with static sealing, zero leakage, long service life, simple installation, safe and environmentally friendly. | ||||
| Remarks | Other special requirements, touch screen intelligent control, program control, and connection to DCS systems shall be designed, manufactured, and configured according to user needs. | ||||
https://luhaochemreactors.en.made-in-china.com/product-list-1.html
| LUHAO Chemical Machinery Co. Ltd | |||||
| Pressure Vessel Design Information Collection Table | |||||
| Vessel | Jacket (Coil) | ||||
| Work Medium | Name | ||||
| Components | |||||
| Density (Kg/m³) | |||||
| Characteristics | |||||
| Viscosity (cP) | |||||
| Flow Velocity(m³/h) | |||||
| Design pressure (Mpa) | |||||
| Work pressure (Mpa) | |||||
| Design temperature(ºC) | |||||
| Work temperature (ºC) | |||||
| Wall temperature (ºC) | |||||
| Diamter (mm) | |||||
| Length (mm) | |||||
| Capacity(m³) | |||||
| Effective capacity (m³) | |||||
| Corrosion allowance (mm) | |||||
| Corrosion speed (mm/year) | |||||
| Recommended Materials | |||||
| Lowest value of average monthly temperature(ºC) | |||||
| Site location | |||||
| Installation condition | Indoor or Outdoor | ||||
| Catalyst Volume(m³) | |||||
| Catalyst Density(Kg/m³) | |||||
| Heat Transfer Area(m2) | |||||
| Coil Specification | |||||
| Basic Wind Pressure(Mpa) | |||||
| Seismic Basic Intensity | |||||
| Ambient Temperature(ºC) | |||||
| Site Type | |||||
| Operating Mode | |||||
| Insulation Materials | Name | ||||
| Thickness | |||||
| Density (Kg/m³) | |||||
| Seal Requirements | |||||
| Liquid Level Gauge | |||||
| Emergency Cut-off | |||||
| Static Electricity Removal | |||||
| Anti Eddy Current Requirement for Liquid Outlet | |||||
| Installation and Mantainance Requirements | |||||
| Expected Useful Life (years) | |||||
| Safety accessories | Vessel | Jacket (Coil) | |||
| Location | |||||
| Type | |||||
| Specification | |||||
| Quantity | |||||
| Set pressure(Mpa) | |||||
| Burst disc | |||||
| Burst pressure(Mpa) | |||||
| Safety discharge(kg/h) | |||||
| Agitator | Type | ||||
| Impeller Diameter(mm) | |||||
| Speed(r/min) | |||||
| Motor | Model | ||||
| Power(kw) | |||||
| Explosion Proof Grade | |||||
| Speed reducer | |||||
