Automatic Full Servo Single Color Screen Printing Machine for Buckets/Bottles/Tubes

Product Description

Automatic Full Servo Single Color Screen Printing Production Line for Buckets/Bottles/Tubes

MODEL	HH-180CNC
Shape of Printed Object	Cylindrical, Cone, Cube, etc.
Max. Printing Area	D: 100mm; L: 300mm
Max. Printing Speed	1000pcs/hr
Printing Accuracy	+/-0.2mm
Air Pressure	6~8 bar
UV Lamp Power	15kw
Power Supply	AC 380V 3Phase 50Hz
Machine Dimension	3000(L)*2600(W)*1660(H)mm
Weight	1500kg

Detailed Photos
Product Parameters
1. Suitable for screen printing on round, oval, square,triangular and other shapes surface of containers (cosmetics, wine, beverage bottles, and general-purpose containers).
2. Adopt full servo drive system.Easy and fast debugging.stable and reliable quality.
3. Germany BECKHOFF motion controller, and 7'touch screen.
4. The tube position holder is controlled and operated by absolute servo motor.
5. The main drive is controlled by high precision reducer with absolute value servo motor.
6. Ball screws and guide rails all adopt international famous brands,which have higher precision and longer life.
7. LED UV curing is also servo-driven.The curing time can be set arbitrarily according to the requirements of product printing, which greatly increases the adhesion of the ink.
8. Printing in the same color on round, oval, square, triangular and other shapes' surface of containers can be completed at one time.
9. Flame treating with servo drive can achieve arbitrary speed adjustment.
10. It can achieve multi-color overprinting and precise control of patterns based on product surface position, via bottle opening or pattern positioning point detection by CCD vision detection.
11. Simple debugging of replacement models without gears. Thus avoiding the inaccuracy of color registration after the wear of the rack and pinion, and significantly save time on tuning.
12. More reasonable design of the main structure and significant optimization over existing domestic machines make it achieve stable and efficient production.Application
Suitable for cylindrical objects printing, such as blow molded bottles, cosmetic tubes, aluminum water bottle, lipstick tubes, glass pipettes, test tubes, jars, syrings etc.
Packaging & Shipping
Packing: Wooden case suitable for export, carton box for small parts.Lead Time: 25 DaysStandards Certificate: CEShipping: By air, by sea, by express (DHL, TNT, UPS, FEDEX,etc)
Company Profile
Howell Print Technology Ltd. is located in Dongguan Guangdong province, covering an area of about 10,000sqm for more than 20 years.
Our company specialized in making pad printing machine & screen printing machine for semi-automatic and fully automatic equipments.
We are a leading manufacturer and exporter of pad printing machine and screen printing machine Since 1996, We making all the parts that designed by our engineer with more than 20 years experience of the printing machines.
OEM and ODM are acceptable.
Our Advantages
1. 20+ Years Experience
Since 1996, Howell started pad&screen printer business in Guangdong as a manufacturer, in the year 2020, we expanded our factory to 10,000 sqm.
2. Professional Team
R&D department, 3 person, OEM&ODM are acceptable; Sales department, 8 international sales and 10 domestic sales.
3. Production Line
7 CNC machines, spare parts made by ourselves and more than 100 sets products output per month.
After Sales Service
We provide one year warranty and life-long maintenance.
Free online training is available.
If necessary, we can also provide field maintenance, but travel charge will be on buyer's side. Online service time:
16 hours online services 8:00 am--12:00pm (Monday- Saturday)
24 hours phone call services (Monday- Sunday)
In order to benefit good rights and interests for our customers, we have done the testing strictly before the machine exports; try to provide the best after-sales service for our customers.FAQ
1. Are you a factory or trading company?
A: We're original manufacturer, more than 20 years experience in machinery industry.
2. Do you support OEM/ODM?A: Yes, we have a professional technique team, we could produce the machine depends on your requirements. 3..How to place order to your company?A: Kindly send inquiry with the details product or email ID to us. 4.What's payment do you support?
A: T/T, Paypal, Western Union, L/C is accepted. 5.What are your main production?
A: We are professional manufacuring in Screen printing machine, Pad printing machine, Ceramic printing Machine and related mechanical accessories.
Welcome your Inquiry!
