Innovo Automatic Knife Grinding Machine

Product Description

INNOVO-E automatic knife grinding machine
Specifications
INNOVO-E automatic knife grinding machine
manufactured by senior engineers
several of oblique knife edge
ideal equipment
low
The mill knife rubs front machine INOVO-EIs Our company the new generation product which develops in the INNOVO-F knife grinder foundation becomes. Is one kind of collection mill knife and polishing (goes to tool mark) to rub the front machine in a body's double wheel head new mill knife.
This function change knife edge angle. The thorough elimination paper cutting cuts the surface the ripple. Extension knife point period of revolution. With bit's service life. The books and periodicals printing shop ideal equipment.
INNOVO-E automatic knife grinding machine Major function disposition:
[Traveling schedule transmission]
01. The master drive is the gear rack drive
[Fuselage part]
02. Hangs the wall type fuselage: The lathe bed uses the strong cast iron casting 03. Wide guide rail: The stability is good, to use high-frequency quenching processing, the intensity high and wear-resisting performance is good
[Work table]
04. Magnet chuck
INNOVO-E automatic knife grinding machine Major technique parameter:
Grinding formation: End surface mill knife, automatic reciprocation
Biggest mill knife length: 1700mm
Tool rest operating angle: 0°-±90°
Grinding wheel rotational speed: 1400 revolution of/minutes
Grinding wheel model: GB cup shape ZR
Grinding wheel specification: Φ200*100* 100mm
Reciprocation speed: 5m/min
Polishing reciprocation speed: 8 m/min
Grinds the electrical machinery: Y90L-4P 1.5KW
Polishes the electrical machinery: YS6314 0.55KW
Reciprocation electrical machinery: YS7124-W 0.55KW
Cooling water pump: JCB-22 0.125KW
Buffing: Φ110*Φ18*12

No	Specification /Model	Biggest grinding length	Outlook size (long * wide * high)	Machine net weight
	3000E	3030	4500*1050*1550	2800
1	1700E	1730	3100*1050*1550	2000
2	2200E	2230	3700*1050*1550	2300

Machine transport and packing
__________________________________________________________________________
1. The packing of small machines is confirm to export wooden case standard, strong and durable. The wooden case's thickness is generally 1 cm.
2. In order to be waterproof, we usually use bubble film to wrap machine.
3. We can handle shipping for customers too.
Our Company:
_____________________________________________________________________

Certificate:
______________________________________________________________________
FAQ:
______________________________________________________________________
Q1: Are you a manufacturer?
Yes, we are specialized manufacturer of hot foil stamping machine and die cutting machine in China over 20 years.
Q2: Do you have stock products to sell?
We manufacture machines in batch. So most of machines have in stock, please check with us before ordering.
Q3: How about installation and training?
Installation and training: If purchaser's engineer travels at own cost to China, free training session. If engineer sent to purchaser's factory, all travel cost paid by purchaser.
Q4: How about warranty?
Warranty period: 12 months from the shipping date of machine. Warranty will be not valid if machine subject to misuse or accidental damage or operator's error. During the valid time, we will supply spare parts. If you have any other questions, pls contact us and we will reply you through product's photos and videos to make every detail clear.
Why choose us?
_____________________________________________________________________
1.Our brand "INNOVO" is well-known in our domestic market and over 80 countries and territories. Europe, South America, Latin America, Southeast Asia, Middle East, Africa etc.
2.Genuine products with excellent quality. Company has always proved the 100% quality.
3.After-sales service and technical assistance: company provides after sales service and technical assistance as per customers' requirement and needs. After-sales service provided engineers available to service machinery overseas.
4.Cost saving: lon-life, shock resistant and high reliability bearings with excellent quality and better performance, resulting in increased cost saving.
5.Less cost of purchase: We are the manufacturer directly.
6.Attendant customers queries promptly.
